Terex Manlift Specifications
Terex is a Westport, Connecticut company that specializes in producing in manufacturing construction machines. machinery like aerial lifts, manlifts and boom lifts. These machinery are designed to facilitate access to difficult to reach areas, roofs and buildings, large equipment, amongst other things. A manlift, as defined by the U.S. Occupational Safety and Health Administration refers to a power-driven endless belt. This belt moves just in one direction and includes platforms, or steps or handholds which are attached to the unit in order to move workers from each floor.
TB85
The TB85 by Terex offers a maximum working height of 91 feet. Moreover, the platform's maximum height reaches 85 feet. The maximum width of this model is 8 feet, 1 and 1/2 inches. The TB85 has dimensions which measure 9 inches wide and 9 feet, 1-inch high by 36 feet. This particular model offers a reach of seventy feet. The TB85 has a boom angle above horizontal reaching 75 degrees and below horizontal measures at -14 degrees.
Terex TB100
The Terex TB100 man lift's maximum height is 106 feet and the platform's maximum height is 100 feet. The TB100 when stowed away, is approximately 9 feet high by 8.5 feet wide by 8 feet. The unit's maximum width is 8 feet, 1 1/2 inches. The boom angle above horizontal is 75 degrees and below horizontal is 14 degrees. The horizontal reach measures at 67 feet, 4 inches.
TB110
The Terex TB110 man lift reaches a max height of 100 feet, whilst the max working height reaches 116 feet. The model is 8 feet wide x 9 feet, 4 inches high The TB110 provides a maximum width of 8 feet and a horizontal reach of 67 feet. This particular model has a boom angle of 75 degrees above horizontal plus 10 degrees articulating. Below horizontal it is -14 degrees and it measures -105 degrees articulating.
